Metal Bellow Capability 1000kg Load Cell Sensor IP67 Protection Class

Metal Bellow Load Cell Sensor

Description

PPM230-BW12 load cell are available in the capacities from 10kg to 1000kg. Stainless steel construction with single shear beam type is adopted. It has good waterproof property because of laser welding technology. It features good accuracy, dynamic response performance, strong anti-overload ability.

PPM230-BW12 is suitable for belt scale, hopper scale, platform scale, sorting scale, and other electronic weighting equipment.

Specification

Capability	10~1000 kg
Comprehensive precision	0.02%FS
Sensitivity	2 mV/V
Creep	±0.02%FS/30min
Zero Output	±1%FS
Temperature effect on zero	±0.02%FS/10℃
Temperature effect on output	±0.02%FS/10℃
Operating temperature range	-20℃~+65℃
Input resistance	380±10Ω
Output resistance	350±3Ω
Insulation resistance	＞5000MΩ
Safe overload	150%FS

Bridge voltage	10V DC
Material	Stainless steel
Protection class	IP 67
Electronic connection	Input+: Red Input-:Black Output+: Green Output-:White
